Semi Automatic Cartoning Machine

Name: Semi Automatic Cartoning Machine
Brand: LEADTOP
Price: 12000 USD

Quality Semi Automatic Cartoning Machine for sale

Brand Name : LEADTOP

Model Number : ZH-50

Certification : CE.ISO

Place of Origin : China

MOQ : 1set

Price : USD12000-15000 per set

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Delivery Time : 30days

Packaging Details : standard export wooden case packing

Product name : semi automatic cartoning machine

usage : blister tube sachet bottle cartoning

Packing speed : 20-50cartons per min

Dimension : 1100*1500*1900MM

Weight : 450Kg

warranty : 1 year

Air pressure : 0.5-0.8Mpa

driven type : Electric

Feature : Easy Operation

Model : ZH-50

power supply : 220V 50HZ single phase

Contact Now

High Speed Semi Linear Automatic Box Cartoning Packing Machine For Cosmetics

APPLICATION :Round bottled medicine, food-stuff, cosmetic, etc. packing into square box.

OPTION :Leaflet Inserting , Hot Glue, Hot Ribbon Date Code , Embossed date Code

FEATURES:
1.It is specially design to pack small quantities multi size box.
2.With low cost and only require small area. It is suitable for various sizes of box. The machine is a vertical type with multiple
function and require a short time to change mould.
3.304 stainless steel case
4.Advanced PLC Control System Combined with 5.7” Colorful Touch Screen Control Panel ,can easily set and change the packing
parameters.

Packing Process:
1.Push box into star wheel.
2.Fold box lower small flap.
3.Press both lower big flaps.
4.Flatten both big flaps.
5.Product fall into box.
6.Fold box upper small flap.
7.Press both upper big flaps.
8.Flatten both big flaps.
9.Product push out

Main Technical Data

Model	ZH-50
Packing speed	20-50 Cartons/min
Carton size range	L(40-125)mm×W(12-80)mm×H(12-80)mm
Carton gram requirements	250-350g/m³
Motor power	1.5KW
Power supply	Three phase 380V 50Hz
Machine noise	≤80dB
Air pressure	0.5-0.8 Mpa
Air consumption	150L/min
Dimension	1100×1500×1900 mm
Weight	250Kg
